TP-LINK 5-PORT GIGABIT DESKTOP SWITCH (TL-SG1005D)

Product Code	TL-SG1005D
Product Model	TP-LINK 5-Port Gigabit Desktop Switch
Condition	Original
Interface	5 10/100/1000Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX
Warranty	3-Year Limited Hardware Warranty
Package Contents	5-Port Gigabit Desktop Switch TL-SG1005D Power Adapter Installation Guide

Features

• 5 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
• Green Ethernet technology saves the power up to 85%
• IEEE 802.3x flow control provides reliable data transfer
• Plastic case, desktop or wall-mounting design
• Plug and play, no configuration required

HARDWARE FEATURES
Interface	5 10/100/1000Mbps RJ45 Ports Auto Negotiation/Auto MDI/MDIX
Fan Quantity	Fanless
Physical Security Lock	No
External Power Supply	External Power Adapter (Output: 9VDC / 0.6A)
Dimensions ( W x D x H )	5.5 × 3.5 × 0.9 in. (140 × 88 × 23 mm)
Max Power Consumption	2.4W
Max Heat Dissipation	8.2 BTU/h

SOFTWARE FEATURES
Transmission Method	Store and Forward
Advanced Functions	Green Technology 802.3x Flow Control Back Pressure 802.1p/DSCP QoS

OTHERS
Certification	FCC, RoHs
Package Contents	5-Port Gigabit Desktop Switch TL-SG1005D Power Adapter Installation Guide
Environment	Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~60℃ (-40℉~140℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
