LOGITECH CRAYON FOR EDUCATION (CLASSIC BLUE) (914-000079)

Power and Connectivity

• Lithium battery
• Upto 7 hours of active writing time
• To turn on, slide the button down towards tip
• After 5 seconds, lights turn off
• When idle, the LED lights will turn on briefly to show battery life when it detects movement, transitioning from idle to active writing mode
• Battery life indicator
  • Battery > 66%, 3 green LED
  • Battery > 33%, 2 green LED
  • Battery >15%, 1 green LED
  • Battery <15%, 1 red blinking LED
• Charge via iPad USB-C cable
• After 5 minutes of inactivity, Crayon will switch to idle mode
• To turn off, slide button up towards charging port
• To charge
  • Charge to 33%, 3 LED blink continuously
  • Charge to 66%, 1 LED is solid green, 2 LED blink continuously
  • Charge to 99%, 2 LED are solid green, 1 LED blink
  • Charge to 100%, 3 solid green LED
