EPSON WIRELESS WXGA 3LCD PROJECTOR EB-1785W (V11H793052)
Remarkable 3LCD Projection At Only 44mm Slim
The Epson EB-1785W packs superior imaging quality along with a suite of connectivity and usability features into a body weighing only 1.83kg and 44mm slim. Wirelessly connect your smart devices to the projector via Wi-Fi, Miracast, iProjection application or NFC technology. The EB-1785W comes with Gesture Presenter technology, which allows you to transit between slides without a clicker. Lastly, with Epson's 3LCD technology that delivers up to 3 times wider colour gamut and brightness, you can astound audiences anywhere you go.
- White Light Output 3,200 lumens, Colour Light Output 3,200 lumens
- WXGA Resolution
- Real-Time Auto Keystone Correction
- Split Screen Projection
- Hassle-Free Presentation with USB 3-in-1 Display Feature and Epson iProjection
The world's slimmest, ultra-portable, 3LCD projector is engineered with convenience in mind. Weighing at most 1.83kg and 44mm thick (excluding the feet), the EB-1785W make mobile presentations easy and hassle free, With up to 3,200 lumens colour and white light output, you can enjoy bright and vibrant images indoors and outdoors.
The EB-1785W is designed with three grip lines at the edges, making them easier and safer to transport. With the projector small footprint, you can carry the projector in a laptop bag to deliver impactful presentations on the move.
Seamless Connectivity and Usability
Ease-of-Presentations with Gesture Presenter
Users can control their presentations conveniently by moving their hands to a white floating marker at the bottom right side of the projection screen. This simple gesture allows users to change to the next slide without using a clicker.
Activate iProjection app seamlessly with the NFC connectivity on your Android smart devices. Simply place them on top of the projector and the iProjection app will be opened.
iProjection* App for Mobile Devices
The iProjection app enables both iOS and Android devices to easily connect to the projector. You can use iProjection to wirelessly project various documents, photos and web pages, and draw on the device screen and share on projection. To connect, search for the projector in your local network or simply scan a QR code displayed on the projector screen. Remote control function is also built into iProjection so you can use the app to control projector functions. In addition, iProjection now supports screen mirroring (without audio) from devices running on Android 5.0 and above.
* In iProjection, projector profile search, multi-screen display, distribution function, audio transfer, movie file transfer, interrupt connection disabling and encryption data transfer capabilities are not supported.
The EB-1785W provide more advanced, real-time auto vertical and horizontal keystone correction. You can conveniently position the projector anywhere in the room. Simply turn on the power and direct the projector towards the screen or wall, and the image will be corrected automatically in no time.
Convenient Wireless Mirroring Projection
Project contents wirelessly from compatible smart devices and laptops without any software installation with the Miracast. The technology enables easy wireless transmission of Full HD video and sound from PCs and smart devices, eliminating the hassle of a physical connection and eradicating issues with setting up. With support for screen mirroring, projecting your tablet and laptop screens has never been easier.
With the quick corner feature, you can use the keystone correction and lens shift function simultaneously for maximum projection without have to worry about unintentionally changing the aspect ratio.
Split screen allows inputs from two separate sources to be displayed side by side on the same screen. In a video conference, for example, images of presentation materials and remote participants can be shown simultaneously.
Auto Power On
With the auto power on function, projection starts automatically once a projection signal is detected via VGA cable, providing you with an easy and hassle-free presentation.
Auto Source Search
With automatic detection of input source, projection automatically begins without you having to manually switch the input.
Enjoy enhanced connectivity and flexibility with in-built Wi-Fi* connectivity. Easily share and transmit images, texts and files from your smart devices using the “Epson iProjection” application for smooth and smart projections.
View and access your most frequently used functions immediately on the home screen. See all source information at a glance, no matter what the source input. With all the information you need right there on the home screen, wireless connections have never been easier.
Better Products for a Better Future™
For more information on Epson's environmental programme, visit http://global.epson.com/SR/environment
What's In The Box:
- Power Cable: 3m
- Computer Cable (VGA Cable): 1.8m
- USB Cable (Type A/B): 3m
- Remote Control: Yes, with Alkaline AA Battery
- Soft Carrying Case
- Bundled Software: CDROM
- Projection Software
- Password Protect Sticker
- Warranty Sheet
Projection Technology:RGB liquid crystal shutter projection system
White Light Output (Normal):3,200lmColour Light Output:Normal / Eco: 3,200lm / 1,900lm
Network:Wireless LAN; In-builtAnalog Input:D-Sub 15 pin; 1(Blue)
Composite; RCA x 1Digital Input:HDMI; 1(MHL)Audio Input:Stereo Mini Jack: 1Others:USB Type A: 1 (for USB Memory, USB Document Camera, Firmware Update)
USB Type B: 1 (for USB Display, mouse, K/B/, Control, Firmware Update)
Supported Speed for Each Mode:IEEE 802.11b: 11Mbps
IEEE 802.11g: 54Mbps
IEEE 802.11n: 130 MbpsWireless LAN Security:Quick Mode: WPA2-PSK
Advanced Mode: WPA2-PSK, WPA/WPA2-PSK, WPA2-EAPSupported EAP type:PEAP, PEAP-TLS, EAP-TLS, EAP-Fast, LEAPSupported Connection Mode:Infrastructure, Access Point
Screen Size (Projected Distance):
Standard Size:60" screen 1.35 - 1.62mZoom : Wide:30" - 300" (0.67 - 6.81m)Zoom : Tele:30" - 300" (0.80 - 8.18m)
Operating Temperature:5°C - 40°C < 41°F - 104°F> (0 m / 0 ft to 2,286m / 7,500ft)
5°C - 35°C < 41°F - 95°F> (over 2,286m / 7,500ft) (20% - 80% humidity, No condensation)
Operating Altitude:0m - 3,000m (0ft - 9,843 ft) (over 1,500m / 4,921ft: with high altitude mode)
Start-Up Period:About 7.2 seconds, Warm-up period: 30 seconds
Cool Down Period:
Cool Down Period:Instant off
Sound Output:Monaural: 1W X 1
Direct Power On/Off:
Direct Power On/Off:Yes/Yes
Dimension Excluding Feet (W x H x D):
Dimension Excluding Feet (W x H x D):292mm x 44mm x 213mm
Fan Noise (Normal / Eco):39 dB / 30dB
Wireless Specifications (Miracast):
Supported Speed for Each Mode:IEEE 802.11g (2.4GHz): 54Mbps
IEEE 802.11n (2.4GHz): 130.0 Mbps
IEEE 802.11a (5GHz): 54 Mbps
IEEE 802.11n (5GHz): 270.0 Mbps
IEEE 802.11ac (5GHz): 780 MbpsSupported Connection Mode:Wi-Fi Direct
Resolution, Projectors Facets:WXGAContrast Ratio, Projectors Facets:10,000:1Brightness Range Lumens, Projectors Facets:2000Laser / Lamp, Projectors Facets:LampFeatures, Projectors Facets:Wifi
