Low Cost Cartridges
Affordable ink cartridges for high quality printing.
Scratch-Resistant Surface
Grid-textured surface is resistant to fingerprints and scratches.
Borderless Printing
Print borderless photos up to 4R size
Specifications
| Print Head / Ink | Type | FINE Cartridge | |||
| Number of Nozzles | Total 1,280 nozzles | ||||
| Ink Cartridges | PG-745S, CL-746S (Optional: PG-745, CL-746 / PG-745XL, CL-746XL) | ||||
| Maximum Printing Resolution*1 | 4800 (horizontal)*2 x 1200 (vertical) dpi | ||||
| Print Speed*2 Based on ISO / IEC 24734. Click here for summary report Click here for Document Print Measurement Conditions |
Document: Col | ESAT / Simplex: Approx. 4.0 ipm | |||
| Document: B/W | ESAT / Simplex: Approx. 7.7 ipm | ||||
| Photo (4 x 6") | PP-201 / Borderless: Approx. 65 sec | ||||
| Printable Width | Up to 203.2 mm (8 inch) | ||||
| Printable Area | Borderless Printing*3 | Top / Bottom / Right / Left margin: each 0 mm (Supported Paper Size: 4 x 6") |
|||
| Bordered Printing | Top margin: 3 mm, Bottom margin: 5 mm, Left / Right margin: each 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm) |
||||
| Recommended Printing Area | Top margin: 31.6 mm / Bottom margin: 29.2 mm | ||||
| Paper Size | A4, LTR, 4 x 6", 5 x 7", Custom size (width 89 - 215.9 mm, length 127 - 676 mm) | ||||
| Paper Handling (Rear Tray) (Maximum Number) |
Plain Paper | A4, LTR = 60 | |||
| Photo Paper Plus Glossy II (PP-201) |
4 x 6" = 20 | ||||
| Glossy Photo Paper "Everyday Use" (GP-508) |
4 x 6" = 20 | ||||
| Photo Paper Plus Glossy II (PP-208) |
4 x 6" = 20 | ||||
| Photo Sticker (Free cutting) (PS-208) |
4 x 6" = 1 | ||||
| Photo Sticker (Free cutting, Removable) (PS-308R) |
4 x 6" = 1 | ||||
| Rear Tray | Plain Paper: 64 - 105 g/m², Canon specialty paper: max paper weight: approx. 275 g/m²(Photo Paper Plus Glossy II (PP-201)) | ||||
| Ink End Sensor | Dot count | ||||
| Print Head Alignment | Manual | ||||
|
System Requirements (Please visit www.canon-asia.com to confirm OS compatibility and to download the latest driver updates) |
Windows: | Windows 10, Windows 8.1, Windows 7 SP1 | |||
| Macintosh: | Mac OS X 10.10.5 ~ 10.11, Mac OS 10.12* * via AirPrint |
||||
| General Specifications | |||||
| Interface | USB 2.0 Hi-Speed | ||||
| Operating Environment*4 | Temperature: | 5 - 35°C | |||
| Humidity: | 10 - 90% RH (no dew condensation) | ||||
| Recommended Environment*5 | Temperature: | 15 -30°C | |||
| Humidity: | 10 - 80% RH (no dew condensation) | ||||
| Storage Environment | Temperature: | 0 - 40°C | |||
| Humidity: | 5 - 95% RH(no dew condensation) | ||||
| Quiet Mode | Available | ||||
| Acoustic Noise (PC Print) | Photo (4 x 6")*6 | Approx. 46.0 dB(A) | |||
| Power | AC 100 - 240 V, 50/60 Hz | ||||
| Power Consumption | OFF | Approx. 0.2 W | |||
| Standby (scanning lamp is off) (USB Connection to PC) |
Approx. 1.2 W | ||||
| Standby (all ports connected, scanning lamp is off) | Approx. 0.9 W | ||||
| Printing*7 | Approx. 10 W | ||||
| Environment | Regulation | RoHS (EU, China), WEEE (EU) | |||
| Dimension (W x D x H) | Factory configuration |
426 x 255 x 131 mm | |||
| Output / ADF trays extended | 426 x 562 x 213 mm | ||||
| Weight | 2.5 kg | ||||
| Specifications are subject to change without notice. | |
| *1 | Ink droplets can be placed with a pitch of 1/4800 inch at minimum. |
| *2 | Document print speeds are the averages of ESAT in Office Category Test for the default simplex mode, ISO / IEC 24734. Photo print speed is based on the default setting using ISO / JIS-SCID N2 on Photo Paper Plus Glossy II and does not take into account data processing time on host computer. Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc. |
| *3 | Paper types NOT supported for borderless printing are as follows: Envelope, High Resolution Paper, T-Shirt Transfer, Photo Stickers |
| *4 | The performance of the printer may be reduced under certain temperature and humidity conditions. |
| *5 | For the temperature and humidity conditions of papers such as photo paper, refer to the paper's packaging or the supplied instructions. |
| *6 | When printing ISO / JIS-SCID N2 on 4 x 6" Photo Paper Plus Glossy II using default settings. |
| *7 | Print: When printing ISO / JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings. |
