Print Head / Ink

Number of Nozzles

Total 1,792 nozzles

Ink Bottles (Type/Colours)

GI-71 (Bundled), GI-71S
(Pigment Ink/Black),
(Dye-based Ink/Cyan, Magenta, Yellow)

Maintenance Cartridge

MC-G04

Print Heads

BH-70, CH-70
(Availability may vary by country)

Maximum Printing Resolution

4,800 (Horizontal)^*1 x 1,200 (Vertical) dpi

Print Speed^*2 (Approx.)

Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions

Document (ESAT/Simplex)^*3

11 / 6 ipm (Mono/Colour)

Document (FPOT Ready/Simplex)^*4

9 / 14 sec (Mono/Colour)

Photo (4 x 6") (PP-201/Borderless)^*5

45 sec

Printable Width

Up to 203.2 m (8")
Borderless: Up to 216 mm (8.5")

Print Margin

Borderless Printing^*63

Top/Bottom/Left/Right margin: 0 mm

Bordered Printing

Envelope (COM10 / DL):
Top/Bottom margin: 12.7 mm
Left/Right margin: 3.4 mm

Envelop (C5 / Monarch):
Top/Bottom margin: 12.7 mm
Left/Right margin: 5.6 mm

B-Oficio, M-Oficio:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 6.4 mm

LTR, LGL, Foolscap, F4, Oficio2:
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 6.3 mm, Right margin: 6.4 mm

Legal (India)
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 5.9 mm

Square 5 x 5" (127 x 127 mm):
Top/Bottom/Left/Right margin: 6 mm

Square 3.5 x 3.5" (89 x 89 mm): Top/Bottom/Left/Right margin: 5 mm

Custom Size:
Width 55 - 216 mm, Length: 89 - 1,200 mm
Top margin: 3 mm, Bottom margin: 5 mm
Left margin: 3.4 mm, Right margin: 3.4 – 9.4 mm

Others:
Top margin: 3 mm, Bottom margin: 5 mm
Left/Right margin: 3.4 mm

Support Media

Rear Tray

Plain Paper (64 - 105 g/m²)
High Resolution Paper (HR-101N)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Plus Semi-Gloss (SG-201)
Photo Paper Pro Luster (LU-101)
Matte Photo Paper (MP-101)
Double-Sided Matte Photo Paper (MP-101D)
Envelope
Photo Stickers (PS-208, PS-808)

Paper Size

Rear Tray

A4, A5, A6, B5, LTR, LGL, Executive, Oficio2,
B-Oficio, M-Oficio, Legal (India), Foolscap, F4,
4 x 6", 5 x 7", 7 x 10", 8 x 10", Envelopes (DL, COM10, C5, Monarch), Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)

[Custom Size]
Width: 55 - 216 mm
Length: 89 - 1,200 mm

Paper Size (Borderless)^*6

A4, B5, LTR, 4 x 6", 5 x 7", 7 x 10", 8 x 10", Square (89 x 89 mm, 127 x 127 mm), Card Size (91 x 55 mm)

Paper Handling (Maximum Number)

Rear Tray

[Plain Paper, A4/LTR]
Plain Paper (64 g/m²): 100
High Resolution Paper (HR-101N): 80

[Photo Paper, 4 x 6"]
Photo Paper Plus Glossy II (PP-201, PP-208): 20
Photo Paper Plus Semi-Gloss (SG-201): 20
Matte Photo Paper (MP-101): 20

Paper Weight

Rear Tray

Plain Paper: 64 - 105 g/m²
Canon Paper: Max. 265 g/m²
(Photo Paper Plus Glossy, PP-201)

Ink End Sensor

Dot count type

Print Head Alignment

Manual

Scanner Type

Flatbed

Scanner Method

Optical Resolution^*8

600 x 1,200 dpi

Scanning Bit Depth (Input/Output)

Greyscale

16 bit / 8 bit

Colour

RGB each 16 bit / 8 bit

Line Scanning Speed^*9  (Approx.)

Greyscale

1.5 ms/line (300 dpi)

Colour

3.5 ms/line (300 dpi)

Maximum Document Size

Flatbed

A4, LTR (216 x 297 mm)

Compatible Media

Size

A4, A5, A6, B5, LTR, Executive (184.2 × 266.7 mm), 4 x 6", 5 x 7", Square (127 x 127 mm), Card Size (91 x 55 mm)

Type

Plain Paper (64 - 105 g/m²)
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Semi-Gloss (SG-201)
Matte Photo Paper (MP-101)

Image Quality

Density Adjustment

9 positions, Auto Intensity (AE copy)

Copy Speed^*10 (Approx.)

Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions

Document (Colour): (sFCOT/Simplex)/ (sESAT/Simplex)

23 sec / 3.2 ipm

Multiple Copy

Mono/Colour

Max. 99 pages

Maximum Document Size

A4, LTR

Protocol

SNMP, HTTP, TCP / IP (IPv4/IPv6)

Wireless LAN

Network Type

IEEE 802.11b/g/n
2.4 GHz, Supported Channels: 1 - 13
(TW: Supported Channels: 1 - 11 only)^*11

Security

WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)
WPA3-SAE (AES)

Direct Connection (Wireless LAN)

Available

AirPrint^®

Available

Mopria^® Print Service

Available

Canon Print Service
(for Android)

Available

Cloud Integration Service
(from smartphone/tablet)

Available

Canon PRINT
(for iOS/Android)

Available

Camera Direct

Wireless LAN

Windows 11 / 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later),

macOS 10.14.6 – 12 or later,

ChromeOS

Operation Panel

Display

1.35" / 3.4 cm Square LCD (Monochrome)

Language

32 Languages Selectable: Japanese, English (mm & inch), French, German, Italian, Spanish, Portuguese, Dutch, Danish, Norwegian, Swedish, Finnish, Greek, Polish, Czech, Russian, Hungarian, Slovene, Turkish, Simplified Chinese, Traditional Chinese, Korean, Indonesian, Slovakian, Estonian, Latvian, Lithuanian, Ukrainian, Romanian, Bulgarian, Croatian, Vietnamese

Interface

USB 2.0

Operating Environment^*13

Temperature

5 - 35°C

Humidity

10 - 90% RH (no dew condensation)

Recommended Environment^*14

Temperature

15 - 30°C

Humidity

10 - 80% RH (no dew condensation)

Storage Environment

Temperature

0 - 40°C

Humidity

5 - 95% RH (no dew condensation)

Quiet Mode

Available

Acoustic Noise (PC Print)^*15 (Approx.)

Plain Paper (A4, Mono)

48.5 dB(A)

Power

AC 100 - 240 V, 50/60 Hz

Power Consumption (Approx.)

OFF

0.1 W

Standby
(USB connection to PC,
scanning lamp is turned off)

0.6 W

Copying^*16
(USB connection to PC)

16 W

Duty Cycle

Up to 3,000 pages/month

Dimensions (WxDxH) (Approx.)

Factory Configuration

416 x 337 x 177 mm

Output/Trays Extended

416 x 557 x 268 mm

Weight (Approx.)

6 kg

Plain Paper
Click here for more information

A4 Colour Documents^*18:
GI-71 PGBK: 6,000 pages (Economy Mode^*19 7,600 pages)
GI-71 C, M, Y: 7,700 pages (Economy Mode^*19 8,100 pages)

GI-71S PGBK: 3,100 pages (Economy Mode^*19 3,900 pages)
GI-71S C, M, Y: 4,400 pages (Economy Mode^*19 4,600 pages)

Photo Paper (PP-201)
Click here for more information

4 x 6" Photos^*20:
GI-71 PGBK: NA
GI-71 C, M, Y: 2,200 sheets

GI-71S PGBK: NA
GI-71S C, M, Y: 1,200 sheets
