5-inch Colour Touchscreen LCD Display
The MF643Cdw features an intuitive 5-inch colour touch screen LCD panel. The operation panel has a vari-angle mechanism which allows greater viewing flexibility.
Description
Designed to keep up with business demands, the MF643Cdw provides in quality of functions.
- Print, Scan, Copy
- Print Speed (A4): Up to 21ppm (mono/colour)
- Print resolution: Up to 1,200 (equivalent) x 1,200dpi (equivalent)
- Gigabit Ethernet, WiFi, Direct Connection
- Recommended Monthly Print Volume: 250 - 2,500 pages
Wireless Freedom
Do away with unsightly cables as the MF643Cdw has the option to share the printer wirelessly within your network. The device also has built in Access Point capability, enabling easy connection to mobile devices without a router.
Mobile Printing Solutions
With Canon’s latest mobile business solution, you can print and scan documents, photos, web pages and emails all with just one app. Click here to find out more!
Auto Document Feeder
A 50-sheet Auto Document Feeder (ADF) performs automated batch copying and scanning of multi-page document originals.
Application Library
The Application Library helps you work smarter and more efficiently. You can store and print frequently-used forms directly from the device, or distribute your documents electronically to pre-set destinations with just a tap of the button.
Built-In PCL Language
The MF643Cdw comes standard with PCL language, enabling the printer to work with a wide range of business applications.
Minimal Maintenance
Enjoy fuss-free and low maintenance operation with Canon All-in-One toner cartridge design. Optional high capacity cartridge 054H is available for customer with high volume printing, reducing the frequency of replacing cartridge even further.
Auto Duplex Printing
Do your part for the environment with the automatic duplex printing feature. Print on both sides to reduce paper wastage while reducing the carbon footprint and operational costs.
QR Code Scan
Simply scan the QR code on the MF643dw to ensure that you are connected to the correct printer when you are using the Canon PRINT Business mobile application.
Technical Specifications
Print
| Printing Method | Colour Laser Beam Printing |
| Print Speed | |
| A4 | 21 / 21 ppm (Mono / Colour) |
| Letter | 22 / 22 ppm (Mono / Colour) |
| 2-Sided | 12 / 12 ppm (Mono / Colour) |
| Print Resolution | 600 x 600 dpi |
| Print Quality with Image Refinement Technology | 1,200 × 1,200 dpi (eq.) |
| Warm up Time (From Power On) | 13 sec or less |
| First Print Out Time (FPOT) | |
| A4 | Approx. 10.4 / 10.5 sec (Mono / Colour) |
| Letter | Approx 10.3 / 10.3 sec (Mono / Colour) |
| Recovery Time (From Sleep Mode) | 6.1 sec or less |
| Print Language | UFR II, PCL 6 |
| Auto Duplex Print | Standard |
| Available Paper Size for Auto Duplex Print | A4, B5, Letter, Legal, Executive, Foolscap, Indian Legal |
| Print Margins | 5mm - top, bottom, left and right (Envelope: 10mm) |
| Print Features | Poster, Booklet, Watermark, Page Composer, Toner Saver |
| Supported File Format for USB Direct Print | Supported File Format: JPEG, TIFF, PDF |
Copy
| Copy Speed A4 | |
| A4 | 21 / 21 ppm (Mono / Colour) |
| Letter | 22 / 22 ppm (Mono / Colour) |
| Copy Resolution | 600 x 600dpi |
| First Copy Out Time (FCOT) | |
| A4 | Approx. 11.4 / 13.4 sec (Mono / Colour) |
| Letter | Approx. 11.2 / 13.1 sec (Mono / Colour) |
| Maximum Number of Copies | Up to 999 copies |
| Reduce/Enlargement | 25 - 400% in 1% increments |
| Copy Features | Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan
| Scan Resolution | |
| Optical | Platen glass: up to 600 x 600dpi Feeder: up to 300 x 300dpi |
| Driver Enhanced | Up to 9,600 x 9,600 dpi |
| Scan Type | Colour Contact Image Sensor |
| Maximum Scan Size | |
| Platen Glass | Up to 216.0 x 297mm |
| Feeder | Up to 216.0 x 355.6mm |
| Scan Speed*1 | 1-Sided: 26.1 ipm (mono), 13.3 ipm (colour) |
| Colour Depth | 24-bit |
| Pull Scan | Yes, USB and Network |
| Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
| Scan To USB (via USB Host 2.0) | Yes |
| Scan To Cloud | MF Scan Utility |
| Scan Driver Compatibility | TWAIN, WIA |
Send
| SEND Method | SMB, Email, FTP |
| Colour Mode | Full Color, Grayscale, Monochrome |
| Scan Resolution | 300 x 600pi |
| File Format | JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Paper Handling
| Auto Document Feeder (ADF) | 50 sheets (80g/m2) |
| Available Paper Size for DADF | A4, B5, A5, Letter, Legal, Statement (Min. 128 x 139.7mm to Max. 216.0 x 355.6mm) |
| Paper Input (based on 80g/m2) |
|
| Standard Cassette | 250 sheets |
| Multi-Purpose Tray | 1 sheet |
| Optional Paper Feeder | N/A |
| Maximum Paper Input Capacity | 251 sheets |
| Paper Output | 100 sheets |
| Paper Sizes | |
| Cassette | A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm) |
| Multi-Purpose Tray | A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card Envelope: COM10, Monarch, C5, DL Custom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm) |
| Optional Paper Feeder | N/A |
| Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
| Paper Weight | |
| ADF | 50 to 105g/m2 |
| Cassette / Optional Paper Feeder |
60 to 200g/m2 |
| Multi-Purpose Tray | 60 to 200g/m2 |
Connectivity & Softwares
| Standard Interfaces | |
| Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
| Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS easy Setup, Direct Connection) |
| Near Field Communication (NFC) | N/A |
| Network Protocol | |
| LPD, RAW, WSD-Print (IPv4,IPv6) | |
| Scan | Email, SMB, WSD-Scan(IPv4, IPv6), FTP |
| TCP/IP Application Services | Bonjour(mDNS), HTTP, HTTPS, POP before SMTP (IPv4,IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
| Management | SNMPv1, SNMPv3 (IPv4,IPv6) |
| Network Security | |
| Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC |
| Wireless | WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES) |
| One-Push Wireless Configuration | Wi-Fi Protected Setup (WPS) |
| Other Features | Department ID, Secure Print, Application Library |
| Mobile Solution | Canon PRINT Business, Canon Print Service, Google Cloud Print™, Apple® AirPrint®, Mopria® Print Service |
| Address Book | LDAP |
| Compatible Operating Systems*2 | Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 Mac® OS X 10.9.5 & up*3, Linux*3 |
| Software Included | Printer driver, Scanner driver, MF Scan Utility, Toner Status |
General
| Device Memory | 1 GB |
| LCD Display | WVGA Colour LCD 5.0" Touch Screen Display |
| Dimensions (W x D x H) | 451 x 460 x 413mm |
| Weight | 20.5 kg |
| Power Consumption | |
| Maximum | 850W or less |
| Average (During Copy) | Approx. 370W |
| Average (During Standby) | Approx. 11W |
| Average (During Sleep) | Approx. 0.8W (USB/ LAN / Wi-Fi) |
| Noise Levels*4 | |
| During Operation | Sound Pressure Level: 51dB Sound Power Level: 69.4dB |
| During Standby | Sound Pressure Level: Inaudible Sound Power Level: 43dB |
| Operating Environment | |
| Temperature | 10 - 30°C |
| Humidity | 20% - 80% RH (no condensation) |
| Power Requirements | AC 220-240 V (±10%), 50/60 Hz (±2Hz） |
| Toner Cartridge*5 | |
| Standard | Cartridge 054 BK: 1,500 pages (bundled: 1,500 pages) Cartridge 054 C/M/Y: 1,200 pages (bundled: 680 pages) |
| High | Cartridge 054H BK: 3,100 pages Cartridge 054H C/M/Y: 2,300 pages |
| Monthly Duty Cycle*6 | 30,000 pages |
- Speed of scanning via the document feeder, A4 size, scan resolution 300 x 300 dpi.
- ScanGear is not available for Windows Server 2003/2008/2012.
- The latest drivers for Mac OS and Linux can be downloaded from the https://asia.canon website when available. Only the print function is supported for Linux.
- Tested in accordance to ISO 7779 and declared per ISO 9296.
- Toner cartridge yield is in accordance with ISO/IEC 19798.
- Monthly Duty Cycle value provides a means of comparison for product robustness in relation to other Canon multi-function laser devices, and does not refer to actual maximum image output per month.
